Rectangular column reinforcement (83): On the Rebar assembly tab, there is now a new setting, Align rebar assembly coordinate system. Select Yes to align the rebar assembly coordinate system with the component coordinate system.

Edge and corner reinforcement (62): The execution time of the component on large slabs with a lot of holes has now been significantly reduced.

Braced girders (88, 89): On the Picture tab, you can now select a new girder type with automatic wave length within a defined range and a new type of side bar geometry. You can also select a profile for the top straight rebar and extra positioning.
In addition, some girder types have been improved to have new front view options to define width and height dimensions.

3D cut (10): Previously, modifying the component by changing the cut type did not always work correctly. The No cut option worked properly only if used when creating the component. This issue has now been fixed.

Braced girder (88), (89): On the Picture tab, there is now a new option, Align rebar assembly coordinate system. Select Yes to align the rebar assembly coordinate system with the component coordinate system.


The Auto splitter component previously did not split all the bars in a curved beam. This issue has now been fixed.

Edge and corner reinforcement (62): Previously, horizontal and vertical stirrups were not created with a combination of Exact spacing values distribution method and long edges. This issue has now been fixed.

Floor layout: Negative values now work in offsets for automatically cut objects.

Floor layout: When working with diagonal cuts, Floor layout now uses the default offset value at a selected floor boundary when you clear the offset value in the contextual toolbar and click the check mark button.

Sandwich wall window: Previously, the component created parts that had 0 volume. These parts are now removed from the model.

Rail connection (70): Previously, notches on secondary parts were created incorrectly. This issue has now been fixed.

Seat det type 1 (1033): Previously, welds were not correctly applied in some cases. This issue has now been fixed.

Bolted gusset (11): Previously, when the gusset plate ran through the main part, the cut was created with an incorrect shape in some cases. This issue has now been fixed.

Stub connection (119): Previously, the top and bottom plate chamfer dimensions were incorrectly applied in the component. This issue has now been fixed.

Railings (S77): Previously, the number of stanchions affected the calculation of railing height. This issue has now been fixed.

Base plate (1004): Previously, the leveling plate was created in an incorrect position in some cases. This issue has now been fixed.

Simple base plate (55): Previously, stiffener chamfer dimensions were incorrectly applied in the component. This issue has now been fixed.

Ayrshire File transfer (92): Previously, the CAM data was incorrectly using the label PURLIN in the ProductType for all Zed and Zeta sections.

Trimble Connect: Various issues regarding the handling of the default upload folder in the Upload model settings dialog have now been fixed.


IFC4 export: Previously, the export of pour objects or pour units failed when you selected the Selected object option. If you selected All objects, the concrete parts forming the pour objects were also exported. These issues have now been fixed.

Attributes in templates: Sometimes the ROW_IN_PAGE attribute did not work correctly in row rules. This issue has now been fixed.

Template Editor: Page breaks were not prevented even though the Use page breaks when height is exceeded option was not selected in the template page properties. This issue has now been fixed.

Pull-out pictures in HTML reports: HTML reports did not show tapered bars in rebar groups in pull-out pictures properly. This issue has now been fixed.

Template Editor: Using the fvf function in reports and drawing templates, a file that worked with spaces in names in Tekla Structures 2022 no longer worked in the latest Tekla Structures versions. This issue has now been fixed.

Pull-out picture dimensions: Previously, in .html reports, pull-out picture dimensions were missing. This issue has now been fixed.

Template Editor: Previously, color indexes were imported as RGB values during the DWG import. Now they are imported as color indexes, which is the correct way. As a result, black color (RGB 0,0,0) is converted to white when black drawing background is in use.

Template Editor: Sometimes the symbol size was incorrect in marks when the symbol was included in a mark template. This issue has now been fixed.

Sometimes, when the regional setting Language for non-Unicode programs in Windows was set to Turkish, templates failed to load. This issue has now been fixed.

Template Editor: Formulas and rules failed when they used the word "IF" that was not part of the actual if-then-else clause. This issue has now been fixed.

Previously, the GetAt() function returned "0" as output even though the value of the argument for it was undefined. It should have returned an empty string. This issue has now been fixed.

Previously, symbols were not printed. This issue has now been fixed.

Annotations: It was sometimes very slow to select and move a large number of annotations that contain a template with custom properties. The performance has now been improved, and selecting and moving annotations is faster.

Drawing hatches: Selecting a hatch for a drawing sketch object, such as a rectangle, did not always work. This issue has now been fixed.

Previously, in specific cases when a drawing was missing the relation to its main part in the model, and you had a complex value for the advanced option XS_SINGLE_PART_DRAWING_VIEW_TITLE, a Tekla Structures application error could occur. This issue has now been fixed.

Tekla Model Sharing: When the model is shared for the first time, the Description property of a shared model now uses by default the description entered in the Project properties.


Rebar sets: The performance of large rebar sets containing multiple coupler or anchor components has been significantly improved.

Rebar shape manager: Tekla Structures now correctly reads valid RebarShapeRules.xml rule files from the model, project, firm, and system folders, in that order.

Curved items, such as ramps, no longer display graphical issues when they are native objects or reference objects.

Filtering: When the Select from model or Multi-select from model option is used with the Template category and with property definitions for MATERIAL, such as MATERIAL.STRENGTH_CLASS, the values are now shown also for pour objects and pour units.

Fillet edges are now displayed with improved performance. You can control the showing and hiding of the edges through the settings.

Area selection from left to right does not select the underlying part anymore if the whole part is not included in the area selection.


Small or thin objects no longer appear overly bright when zooming out in rendered model views.

Previously, workplane related template attributes were not working in model view filters and selection filters. This has now been fixed.

Previously, the Building hierarchy commands for manual assignment of assemblies were not always shown on the context menu when they should have been shown. This issue has now been fixed.


Previously, the contextual toolbar for parts sometimes did not display the dropdown for material. This has now been fixed.

Previously, the middle height of some profiles was not calculated correctly. The middle height is now calculated correctly.

Previously, in certain cases, clicking too quickly when switching between model and drawing could cause old property dialogs to appear. This has now been fixed.

Before, the TSEP installer did not allow different extensions with the same name to be installed at the same time. Now, the TSEP installer decides based on the upgrade code whether it can install and upgrade extensions.

Previously, Tekla Structures might have stopped working unexpectedly when you closed and reopened a plugin component dialog. This has now been fixed.

Earlier, clicking the Create button in a component dialog did not work correctly after you had selected another component of the same class in the Applications & components catalog and created it in the model. Clicking the Create button started the command of the component you just created instead of the component where you clicked the Create button. This issue has now been fixed.

Exporting UDAs from reports is now possible.

When exporting a Drawings for external approval package or a Fabrication package, the .trb file name is now the Tekla Structures model project name.

Export Unitechnik (79): On the SLABDATE block data specification tab, you can now specify the type of the Slab area for the export. The options are Gross area, Net area with cutouts, Net area without cutouts, and Template.
