XS_MARK_ALL_BOLT_GROUPS_SEPARATELY
Category in Advanced options dialog: Marking - bolts
Set this advanced option to
TRUE to prevent
Tekla Structures from combining bolt group marks. By default
Tekla Structures combines bolt group marks (FALSE).
This advanced option is model specific and the setting is saved in the options database.
Example
In the image below, this advanced option is set to
TRUE.
In the image below,
FALSE is used.
